Weichai P10.340 Wp10 Diesel Engine 340HP for Shacman Truck Cement Mixer Truck

5 0 Reviews
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • P10.340

  • weichai

发动机海报

The P10.340 is a robust and efficient 6-cylinder, in-line, 4-stroke diesel engine renowned for its exceptional durability, reliable power, and superior fuel economy . With a substantial 9.726-liter displacement and featuring turbocharged and intercooled aspiration, this water-cooled engine is engineered to deliver consistent performance in the most demanding transportation and construction environments . Its proven technology and robust construction make it a trusted power source for a wide range of heavy-duty trucks and machinery .

Key Technical Specifications

For a quick overview, here are the core specifications of the P10.340 engine:

Parameter Specification
Configuration In-line, 6-Cylinder, 4-Stroke
Aspiration Turbocharged and Intercooled
Displacement 9.726 L
Bore × Stroke 126 mm × 130 mm (for similar WP10.336 model)
Rated Power/Speed 250 kW (340 hp) @ 1900 rpm
Max. Torque/Speed 1250 N.m @ 1400-1600 rpm
Fuel System Electronic
Emission Standard Euro II
Dimensions (L×W×H) 1525 mm × 730 mm × 1063 mm

Note: Specifications can vary depending on the specific application configuration.

Primary Applications & Equipment

The P10.340 engine is built to be the powerhouse behind a range of heavy-duty equipment:

  • Heavy-Duty Trucks: It is a key power source for Sinotruk HOWO trucks and other heavy-duty transportation vehicles .

  • Construction Machinery: This engine is also applied in various construction machinery, providing reliable power for demanding tasks .

Core Technologies & Key Features

  • Turbocharged and Intercooled Aspiration: The turbocharged and intercooled system forces more dense, cool air into the cylinders, significantly boosting power output and torque while optimizing combustion for improved fuel efficiency and lower emissions .

  • Rugged Engine Design: Built for maximum durability, the engine features a sturdy construction to ensure a long service life in tough conditions .

  • Electronic Power Management: The engine is equipped with an electronic power system, contributing to its reliable performance .
